We own all types of facilities necessary to develop the materials and components associated with electrical energy storage devices.

⇒Please consult us for a tour of these facilities.

Synthesis furnaces of several types of atmospheres and CHNSO microelement analysis device
Pulverization, classification and particle distribution measuring devices
Pore distribution measuring and analyzing device: QSDFT method analysis
Planetary mixer, rotation and revolution type mixing and deforming device, nano disperser, etc.
Thin film revolution type high-speed mixer and roll kneader
Continuous electrode coating device and (cold and hot) rolling press machines
Ar atmosphere dry box capable of vacuum drying process at 600°C
Dry room Ⅱ for prototyping and analyses of electrodes at low dew points
High speed data logging charge-discharge test machine
High precision charge-discharge test system for "current-rest-method" and deterioration analysis
XPS (non-exposure), XPD, (In-situ) EF-SEM (non-exposure), IR (non-exposure), AFM, DSC, 3-D thermal diffusion coefficient, etc.

Prototyping facilities for small, medium and large-size batteries (for cylindrical, laminated and hard case types)
Laser, ultrasonic and resistance welders
Vacuum immersion device
Dry room, Ar atmosphere dry box (prototyping of batteries and dismantling of medium and large-size batteries)
Charge-discharge test system: 5 to 72 V/μA to 400 A maximum
Module charge-discharge test building (Osaka)
Several constant temperature tanks: from −40 to 100°C, anti-explosion type
Small-size battery safety evaluation and analysis device (Kyoto)
Medium and large-size battery safety evaluation and analysis device

2016.8
